Mechanical fabrication, assembly & production drawing services
Mechanical fabrication drawing services that keep production moving.
Turn models, markups and standards into assembly drawings, manufacturing drawings, weldment documentation and sheet metal drafting packages — with the BOMs and parts lists production teams use every day.
Choose a qualified specialist, run production in a secure cloud workspace and review organized drawing packages at defined milestones.
Defined deliverables
Clear drawings, BOMs and production documentation for manufacturing teams.
OUTPUTTYPICAL INPUTDELIVERED FOR
Fabrication drawingsApproved models, templates, standardsShop-floor and supplier communication
Assembly drawingsApproved assemblies and item rulesRelease packages and work instructions
Manufacturing drawingsApproved parts, tolerancing and annotation rulesDetail drawings for production and inspection
BOMs & parts listsApproved assemblies, item and part-number rulesStructured manufacturing BOMs and drawing parts lists
Weldment documentationWeldment models, supplied symbols and notesFabrication reference and client review
Sheet metal draftingPart models, bend rules, material specsFlat patterns, DXF outputs, bend notes and cut lists
Exploded viewsAssemblies and sequence rulesKitting, service and assembly documentation
Revision packagesRedlines and approved ECO instructionsUpdated production drawing sets
Built around your workflow
Every drawing package follows your templates, standards, annotation rules and review gate. Missing dimensions, unclear weld callouts and undefined tolerances are raised as questions for your reviewer, not resolved by assumption.
Why teams use it
Turn models and production requirements into usable drawing packages.
View creation, annotation, BOM and parts-list preparation, redline incorporation and package consistency all consume valuable capacity. Giga Techspace gives that production work a dedicated path from a rough brief to an organized package.
